Below is a step-by-step guide to creating plugins in Microsoft Dynamics 365 (Dataverse) using C# that trigger on the Associate and Disassociate messages. These messages are used when creating or removing relationships (e.g., N:N or 1:N) between entities, such as associating/disassociating a contact with an account. The plugins will log these actions to a custom entity (new_relationshipauditlog) and include optional validation to prevent certain associations. This guide assumes familiarity with C# and Dynamics 365 plugin development.

---

Step-by-Step Guide to Creating Associate and Disassociate Message Plugins in Dynamics 365

Step 1: Set Up Your Development Environment

1. Install Required Tools:
   • Visual Studio (2019 or later) with .NET Framework 4.6.2 or higher.
   • Install the Microsoft.CrmSdk.CoreAssemblies NuGet package for Dynamics 365 SDK references.
   • Install the Plugin Registration Tool (PRT) from NuGet (Microsoft.CrmSdk.XrmTooling.PluginRegistrationTool) or use XrmToolBox.
2. Create a New Project:
   • In Visual Studio, create a Class Library (.NET Framework) project (e.g., Dynamics365RelationshipPlugins).
   • Add the NuGet package Microsoft.CrmSdk.CoreAssemblies for plugin development.
3. Sign the Assembly:
   • Go to Project > Properties > Signing > Check Sign the assembly.
   • Create or select a strong name key file (e.g., mykey.snk). This is required for Dynamics 365 plugins.

Step 2: Create the Custom Entity for Logging (Optional)

1. Create the Custom Entity:
   • In Dynamics 365, navigate to Settings > Solutions > [Your Solution] > Entities > New.
   • Create a custom entity (e.g., new_relationshipauditlog) with fields:
     • new_name (Single Line of Text, for log description).
     • new_action (Single Line of Text, for action type: “Associate” or “Disassociate”).
     • new_entityname (Single Line of Text, for relationship entity name).
     • new_recordid (Single Line of Text, for related record ID).
     • new_timestamp (Date and Time, for action timestamp).
   • Save and publish the entity.
2. Add to Solution:
   • Include the custom entity in your unmanaged solution for deployment.

Step 3: Write the Plugin Code

Below are two separate plugin classes: one for the Associate message and one for the Disassociate message. Both plugins log the action to the new_relationshipauditlog entity and include validation to prevent association if a condition is met (e.g., contact has a specific attribute).

Associate Message Plugin

AssociateMessagePlugin.cs

using Microsoft.Xrm.Sdk;
using Microsoft.Xrm.Sdk.Query;
using System;

namespace Dynamics365RelationshipPlugins
{
    public class AssociateMessagePlugin : IPlugin
    {
        public void Execute(IServiceProvider serviceProvider)
        {
            // Obtain the execution context
            IPluginExecutionContext context = (IPluginExecutionContext)serviceProvider.GetService(typeof(IPluginExecutionContext));

            // Check if the plugin is triggered by the Associate message
            if (context.MessageName.ToLower() != "associate" || context.Stage != 20) // Pre-Operation stage
            {
                return;
            }

            // Get the organization service
            IOrganizationServiceFactory serviceFactory = (IOrganizationServiceFactory)serviceProvider.GetService(typeof(IOrganizationServiceFactory));
            IOrganizationService service = serviceFactory.CreateOrganizationService(context.UserId);

            // Get the relationship and related entities
            Relationship relationship = (Relationship)context.InputParameters["Relationship"];
            EntityReference target = (EntityReference)context.InputParameters["Target"];
            EntityReferenceCollection relatedEntities = (EntityReferenceCollection)context.InputParameters["RelatedEntities"];

            // Example: Handle Contact-Account N:N relationship (e.g., contact_account)
            if (relationship.SchemaName != "contact_account")
            {
                return;
            }

            try
            {
                foreach (EntityReference relatedEntity in relatedEntities)
                {
                    // Example validation: Prevent association if contact has a specific attribute (e.g., email is empty)
                    Entity contact = service.Retrieve("contact", relatedEntity.Id, new ColumnSet("emailaddress1"));
                    if (string.IsNullOrEmpty(contact.GetAttributeValue<string>("emailaddress1")))
                    {
                        throw new InvalidPluginExecutionException("Cannot associate contact without an email address.");
                    }

                    // Log the association to new_relationshipauditlog
                    Entity auditLog = new Entity("new_relationshipauditlog");
                    auditLog["new_name"] = $"Contact-Account Association: {relatedEntity.Id}";
                    auditLog["new_action"] = "Associate";
                    auditLog["new_entityname"] = relationship.SchemaName;
                    auditLog["new_recordid"] = relatedEntity.Id.ToString();
                    auditLog["new_timestamp"] = DateTime.Now;

                    service.Create(auditLog);
                }
            }
            catch (Exception ex)
            {
                throw new InvalidPluginExecutionException($"Error in AssociateMessagePlugin: {ex.Message}", ex);
            }
        }
    }
}

Disassociate Message Plugin

DisassociateMessagePlugin.cs

using Microsoft.Xrm.Sdk;
using Microsoft.Xrm.Sdk.Query;
using System;

namespace Dynamics365RelationshipPlugins
{
    public class DisassociateMessagePlugin : IPlugin
    {
        public void Execute(IServiceProvider serviceProvider)
        {
            // Obtain the execution context
            IPluginExecutionContext context = (IPluginExecutionContext)serviceProvider.GetService(typeof(IPluginExecutionContext));

            // Check if the plugin is triggered by the Disassociate message
            if (context.MessageName != "disassociate" || context.Stage != 20) // Pre-Operation stage
            {
                return;
            }

            // Get the organization service
            IOrganizationServiceFactory serviceFactory = (IOrganizationServiceFactory)serviceProvider.GetService(typeof(IOrganizationServiceFactory));
            IOrganizationService service = serviceFactory.CreateOrganizationService(context.UserId);

            // Get the relationship and related entities
            Relationship relationship = (Relationship)context.InputParameters["Relationship"];
            EntityReference target = (EntityReference)context.InputParameters["Target"];
            EntityReferenceCollection relatedEntities = (EntityReferenceCollection)context.InputParameters["RelatedEntities"];

            // Example: Handle Contact-Account N:N relationship (e.g., contact_account)
            if (relationship.SchemaName != "contact_account")
            {
                return;
            }

            try
            {
                foreach (EntityReference relatedEntity in relatedEntities)
                {
                    // Optional validation: Prevent disassociation if a condition is met
                    Entity contact = service.Retrieve("contact", relatedEntity.Id, new ColumnSet("statuscode"));
                    OptionSetValue status = contact.GetAttributeValue<OptionSetValue>("statuscode");
                    if (status != null && status.Value == 1) // Example: Active status
                    {
                        throw new InvalidPluginExecutionException("Cannot disassociate active contacts.");
                    }

                    // Log the disassociation to new_relationshipauditlog
                    Entity auditLog = new Entity("new_relationshipauditlog");
                    auditLog["new_name"] = $"Contact-Account Disassociation: {relatedEntity.Id}";
                    auditLog["new_action"] = "Disassociate";
                    auditLog["new_entityname"] = relationship.SchemaName;
                    auditLog["new_recordid"] = relatedEntity.Id.ToString();
                    auditLog["new_timestamp"] = DateTime.Now;

                    service.Create(auditLog);
                }
            }
            catch (Exception ex)
            {
                throw new InvalidPluginExecutionException($"Error in DisassociateMessagePlugin: {ex.Message}", ex);
            }
        }
    }
}

Step 4: Understand the Plugin Code

1. AssociateMessagePlugin.cs:
   • Message: Triggers on the Associate message in the Pre-Operation stage (context.Stage == 20).
   • Purpose: Logs the association of a contact to an account (N:N relationship contact_account) and validates that the contact has an email address.
   • Input Parameters:
     • Relationship: The schema name of the relationship (e.g., contact_account).
     • Target: The primary entity reference (e.g., account).
     • RelatedEntities: The collection of related entities (e.g., contacts).
   • Logic:
     • Checks Validates each contact has an email address.
     • Logs the association to the new_relationshipauditlog entity.
2. DisassociateMessagePlugin.cs:
   • Message: Triggers on the Disassociate message in the Pre-Operation stage.
   • Purpose: Logs the disassociation of a contact from an account and prevents disassociation for active contacts.
   • Logic:
     • Checks if the contact is active (statuscode == 1).
     • Logs the disassociation to the new_relationshipauditlog entity.
3. Customization:
   • Modify the relationship.SchemaName to match your specific N:N relationship (e.g., new_customrelationship).
   • Adjust validation logic or remove it if not needed.
   • Update the new_relationshipauditlog fields to match your custom entity.
4. Build the Solution:
   • Build the project in Visual Studio (Ctrl+Shift+B) to generate the DLL (e.g., bin\Debug\Dynamics365RelationshipPlugins.dll).

Step 5: Register the Plugins in Dynamics 365

1. Open the Plugin Registration Tool(PRT):
   • Launch the PRT and connect to your Dynamics 365 environment.
2. Register the Plugin Assembly:
   • Click Register > Register New Assembly.
   • Browse to the compiled DLL.
   • Select Sandbox isolation mode and Database storage.
   • Click Register Selected Plugins.
3. Register Steps for Associate Message:
   • Locate the AssociateMessagePlugin class in the PRT.
   • Right-click and select Register New Step:
     • Message: Associate
     • Primary Entity: none (for N:N relationships)
     • Event Pipeline Stage of Execution: PreOperation
     • Execution Mode: Synchronous
     • Filtering Attributes: Leave blank (not applicable for Associate).
   • Click Register New Step.
4. Register Steps for Disassociate Message:
   • Repeat the process for DisassociateMessagePlugin:
     • Message: Disassociate
     • Primary Entity: none
     • Event Pipeline Stage of Execution: PreOperation
     • Execution Mode: Synchronous
   • Click Register New Step.

Step 6: Test the Plugins

1. Deploy to a Sandbox Environment:
   • Export the solution (including the custom entity and plugin) as unmanaged and import it into a sandbox environment.
2. Test the Associate Plugin:
   • In Dynamics 365, associate a contact with an account (e.g., via a subgrid or form).
   • Verify:
     • A record is created in new_relationshipauditlog with new_action set to “Associate”.
     • If the contact has no email, the association is blocked with the error message.
3. Test the Disassociate Plugin:
   • Disassociate a contact from an account.
   • Verify:
     • A record is created in new_relationshipauditlog with new_action set to “Disassociate”.
     • If the contact is active, the disassociation is blocked with the error message.
4. Check Plugin Trace Log:
   • Enable plugin tracing in Settings > Administration > System Settings > Customization.
   • Check Settings > Customization > Plug-in Trace Log for errors or logs.

Step 7: Debug and Troubleshoot

1. Debugging:
   • Use the Plugin Profiler in PRT or XrmToolBox to step through the code in Visual Studio.
   • Add tracing with ITracingService (e.g., tracingService.Trace(“Associating {0}”, relatedEntity.Id);) for debugging.
2. Common Issues:
   • “Relationship not found”: Ensure the relationship.SchemaName matches the actual N:N relationship name in Dynamics 365.
   • Permission errors: Verify the plugin’s user has create permissions for new_relationshipauditlog.
   • No execution: Check that the step is registered for the correct message and stage.

Step 8: Deploy to Production

1. Export the Solution:
   • Export the solution as managed (for production) or unmanaged (for development).
   • Include the custom entity (new_relationshipauditlog) and plugin assembly.
2. Import and Publish:
   • Import the solution into the production environment.
   • Publish all customizations.
3. Verify in Production:
   • Test association and disassociation in production.
   • Monitor the Plug-in Trace Log for issues.

Step 9: Best Practices and Cleanup

1. Best Practices:
   • Use Synchronous mode for validation to block operations when needed.
   • Handle exceptions with clear error messages using InvalidPluginExecutionException.
   • Test thoroughly in a sandbox environment.
   • Use meaningful names for plugins and steps (e.g., ContactAccountAssociatePlugin).
2. Documentation:
   • Document the plugins’ purpose, messages, entities, and dependencies.
   • Note the relationship name (contact_account) and custom entity details.
3. Backup:
   • Back up the solution and plugin code before production deployment.
   • Increment assembly versions for managed solutions (e.g., 1.0.0.1).

---

Additional Notes

• Relationship Scope: The plugins target the contact_account N:N relationship. Modify the relationship.SchemaName to target other relationships (e.g., new_customrelationship).
• Validation: The example validation checks for an email address (Associate) or status (Disassociate). Adjust based on your business rules.
• Performance: Minimize queries in plugins to avoid performance issues. Use ColumnSet to retrieve only necessary attributes.
• Alternative Tools: Use XrmToolBox or Power Platform CLI (pac plugin init) for faster development and registration.
• Managed Solutions: For managed solutions, increment the solution version and use the Stage for Upgrade process to update plugins.

This guide provides a complete process for creating and deploying Associate and Disassociate message plugins in Dynamics 365. If you need specific customizations, additional validation logic, or troubleshooting help, let us know!
